Isolating transducer

IM33-11EX-HI/24VDC

Order ID no. 7506440

Number of channels: 1
Ex version: yes
Power supply: 24 VDC
Protection class: IP20
Electrical connection: 4 × 3-pin removable terminal blocks with test socket, reverse polarity protected, screw terminal
Housing material: Plastic
Housing quality: Polycarbonate/ABS
Ambient temperature min. (°C): -25
Ambient temperature max. (°C): 70
Approvals: ATEX, IECEx, UL, cFMus, TR CU, TIIS, CCOE, Metrological Approval Russia, KOSHA
Signal type: Analog input (HART transparent)
Nominal voltage: 24 VDC
Approvals: ATEX, IECEx, UL, cFMus, TR CU, TIIS, CCOE
