Incremental Encoder
REI-04Q6C-2H200-H1181
Order ID no. 100011151| In Stock | |
| List Price | PLN 1,190.58 |
Item TotalPLN 1,190.58
Quantity
- Protection class
- IP65
- Electrical connection
- Connector
- Connector type
- M12 × 1
- Housing material
- Aluminum chromated
- Ambient temperature min.
- -20
- Ambient temperature max.
- 85
- Measuring principle
- Optical
- Output type
- Incremental
- Shaft Type
- Solid shaft
- Shaft diameter D (mm)
- 6
- Flange diameter
- 36.5
- Flange type
- Clamping flange
- Resolution, incremental
- 200
- Output function
- , Push-Pull/HTL
Key Features
- Output type
- Incremental
- Flange diameter
- 36.5
- Shaft diameter D (mm)
- 6
- Shaft Type
- Solid shaft
