Pressure Transmitter
PT1VR-1013-U1-WM0.5
Order ID no. 100002407| In Stock | |
| Price Group | J1 |
| List Price | PLN 642.42 |
Item TotalPLN 642.42
Quantity
- Design
- Without display
- Process connection
- G1/8″ male thread (back sealing) according to DIN EN ISO 1179-2 with FPM profile sealing ring
- Electrical output
- Voltage output (3-wire)
- Protection class
- IP65
- Electrical connection
- Stranded wires
- Connector type
- Open end
- Housing material
- Stainless-steel/Plastic
- Housing quality
- 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
- Ambient temperature min.
- -30
- Ambient temperature max.
- 85
- Approvals
- cULus
- Media temperature min.
- -40
- Media temperature max.
- 125
- Pressure type
- Relative pressure
- Material pressure transducer
- Ceramic Al₂O₃
- Operating voltage
- DC
- Output function
- , Analog output voltage
- Pressure range
- -1…0 bar
Key Features
- Electrical output
- Voltage output (3-wire)
- Process connection
- G1/8″ male thread (back sealing) according to DIN EN ISO 1179-2 with FPM profile sealing ring
- Pressure range
- -1…0 bar
