PT25R-1041-U1-H1141/X | TURCK - Your Global Automation Partner
Pressure Transmitter
PT25R-1041-U1-H1141/X
Order ID no. 100002685
In Stock
Price Group
J1
List Price
PLN 664.83
home
Home
Loading...
Technical Data
Design
Without display
Process connection
M10 × 1 DIN 3852-E (rear sealing)
Electrical output
Voltage output (3-wire)
Protection class
IP67
Electrical connection
Connector
Connector type
M12 × 1
Housing material
Stainless-steel/Plastic
Housing quality
1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Ambient temperature min. (°C)
-30
Ambient temperature max. (°C)
85
Approvals
cULus
Media temperature min. (°C)
-40
Media temperature max. (°C)
125
Pressure type
Relative pressure
Material pressure transducer
Ceramic Al₂O₃
Operating voltage
DC
Output function
, Analog output voltage
Pressure range
0…25 bar
Key Features
Electrical output
Voltage output (3-wire)
Process connection
M10 × 1 DIN 3852-E (rear sealing)
Pressure range
0…25 bar
