Pressure Transmitter
PT600R-2103-I2-KO28A2
Order ID no. 100003575| In Stock | |
| Price Group | J1 |
| List Price | PLN 705.49 |
Item TotalPLN 705.49
Quantity
- Design
- Without display
- Process connection
- 1/4″ NPT-18 male thread
- Electrical output
- Current output (2-wire)
- Protection class
- IP69K
- Electrical connection
- Connector
- Connector type
- Kostal SLK 2.8 A-coding
- Housing material
- Stainless-steel/Plastic
- Housing quality
- 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
- Ambient temperature min. (°C)
- -40
- Ambient temperature max. (°C)
- 100
- Approvals
- cULus
- Media temperature min. (°C)
- -40
- Media temperature max. (°C)
- 125
- Pressure type
- Relative pressure
- Material pressure transducer
- Stainless steel 1.4404 (AISI 316L)
- Operating voltage
- DC
- Output function
- , Analog output current
- Pressure range
- 0…600 bar
Key Features
- Electrical output
- Current output (2-wire)
- Process connection
- 1/4″ NPT-18 male thread
- Pressure range
- 0…600 bar
