PT600R-2121-I2-KO28A2 | TURCK - Your Global Automation Partner
Pressure Transmitter
PT600R-2121-I2-KO28A2
Order ID no. 100003604
home
Home
Loading...
Technical Data
Design
Without display
Process connection
9/16″-18 UNF male thread
Electrical output
Current output (2-wire)
Protection class
IP69K
Electrical connection
Connector
Connector type
Kostal SLK 2.8 A-coding
Housing material
Stainless-steel/Plastic
Housing quality
1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Ambient temperature min. (°C)
-40
Ambient temperature max. (°C)
100
Media temperature min. (°C)
-40
Media temperature max. (°C)
125
Pressure type
Relative pressure
Material pressure transducer
Stainless steel 1.4404 (AISI 316L)
Operating voltage
DC
Output function
, Analog output current
Pressure range
0…600 bar
Key Features
Electrical output
Current output (2-wire)
Process connection
9/16″-18 UNF male thread
Pressure range
0…600 bar
