PT600R-2149-I2-AMPS1.5 | TURCK - Your Global Automation Partner
Pressure Transmitter
PT600R-2149-I2-AMPS1.5
Order ID no. 100003612
home
Home
Loading...
Technical Data
Design
Without display
Process connection
G 3/8'' male thread
Electrical output
Current output (2-wire)
Protection class
IP67
Electrical connection
Connector
Connector type
AMP Superseal 1.5
Housing material
Stainless-steel/Plastic
Housing quality
1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Ambient temperature min. (°C)
-40
Ambient temperature max. (°C)
100
Media temperature min. (°C)
-40
Media temperature max. (°C)
125
Pressure type
Relative pressure
Material pressure transducer
Stainless steel 1.4404 (AISI 316L)
Operating voltage
DC
Output function
, Analog output current
Pressure range
0…600 bar
Key Features
Electrical output
Current output (2-wire)
Process connection
G 3/8'' male thread
Pressure range
0…600 bar
