PT5000PSIG-2018-I2-DA91 | TURCK - Your Global Automation Partner
Pressure Transmitter
PT5000PSIG-2018-I2-DA91
Order ID no. 100003898
home
Home
Loading...
Technical Data
Design
Without display
Process connection
7/16″-20 UNF female thread
Electrical output
Current output (2-wire)
Protection class
IP65
Electrical connection
Connector
Connector type
DIN EN 175301-803 Form A
Housing material
Stainless-steel/Plastic
Housing quality
1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Ambient temperature min. (°C)
-30
Ambient temperature max. (°C)
85
Approvals
cULus
Media temperature min. (°C)
-40
Media temperature max. (°C)
135
Pressure type
Relative pressure
Material pressure transducer
Stainless steel 1.4435 (AISI 316L)
Operating voltage
DC
Output function
, Analog output current
Pressure range
0…344.74 bar
Key Features
Electrical output
Current output (2-wire)
Process connection
7/16″-20 UNF female thread
Pressure range
0…344.74 bar
In Stock
Price Group
J1
List Price
PLN 642.42
