PT400R-2121-I2-H1144 | TURCK - Your Global Automation Partner
Pressure Transmitter
PT400R-2121-I2-H1144
Order ID no. 100023802
home
Home
Loading...
Technical Data
Protection class
IP69K
Design
Without display
Process connection
9/16″-18 UNF male thread
Electrical connection
Connector
Connector type
M12 × 1
Housing material
Stainless-steel/Plastic
Housing quality
1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Media temperature min.
-40
Media temperature max.
125
Ambient temperature min.
-40
Ambient temperature max.
100
Operating voltage
DC
Electrical output
Current output (2-wire)
Pressure type
Relative pressure
Material pressure transducer
Stainless steel 1.4404 (AISI 316L)
Output function
, Analog output current
Pressure range
0…400 bar
Key Features
Electrical output
Current output (2-wire)
Process connection
9/16″-18 UNF male thread
Pressure range
0…400 bar
In Stock
List Price
PLN 679.61
