Temperature Detection
TP-206A-CF-H1141-L350
Order ID no. 9910609| In Stock | |
| Price Group | D2 |
| List Price | PLN 296.50 |
Item TotalPLN 296.50
Quantity
- Detection type
- medium contact
- Design
- Temperature probe
- Immersion depth L
- 350
- Process connection
- For compression fittings, thermowell or direct mounting
- Electrical output
- Resistance
- Protection class
- IP67
- Electrical connection
- Connector
- Connector type
- M12 × 1
- Housing material
- Stainless steel
- Housing quality
- 1.4404 (AISI 316L)
- Ambient temperature min.
- -40
- Ambient temperature max.
- 120
- Approvals
- cULus
- Mounting conditions
- Immersion sensor
- Measuring range
- -50…500 °C
Key Features
- Electrical output
- Resistance
- Process connection
- For compression fittings, thermowell or direct mounting
- Measuring range
- -50…500 °C
