Inductive Sensor

NI12U-MT18-ADZ30X2

Order ID no. 4209420

Ambient temperature max. (°C): 85
Ambient temperature min. (°C): -30
Cable length (m): 2
Construction size: ⌀ 18 mm
Design: Threaded barrel
Electrical connection: Cable
Housing material: Metal
Housing quality: CuZn
Housing surface: PTFE-coated
Mounting conditions: Non-flush
Operating voltage: AC/DC
Protection class: IP68
Quality active face: PBT
Rated switching distance (mm): 12
Special features: Factor 1, PTFE-coated, Resistant to magnetic fields, uprox+
Switching element function: NO contact
Switching frequency (kHz): 0.02
