Photoelectric Sensor
QM26VPAF400Q5
Order ID no. 3028731
In Stock
Price Group
D1
List Price
PLN 1,606.94
Item Total
PLN 1,606.94
Quantity
−
+
add_shopping_cart
Add to Cart
Contact Support
home
Turck-Shop
Sensors
Photoelectric Sensors
QM26VPAF400Q5
Technical Data
Downloads
Special features
Chemical-resistant, Wash down, Resistant to chemicals
Ambient temperature max. (°C)
70
Ambient temperature min. (°C)
-30
Cable length (m)
0.15
Electrical connection
Cable with connector
Connector type
M12 x 1
Design
Rectangular
Dimensions
15,3 mm x 14 mm x 32,6 mm
Housing material
Metal
Housing quality
Stainless steel
Housing surface
Grey
Light type
Red
Function
Proximity switch
Operating mode
Background suppression, adjustable
Protection class
IP69
Max. range (mm)
400
Setting option
Screw Adjustment
Switching element function
Complementary contact
Switching frequency (kHz)
2
Wavelength (nm)
620
Key Features
Light type
Red
Function
Proximity switch
Max. range (mm)
400
