Pressure Transmitter
PT40R-2045-IOL-H1141
Order ID no. 100031874
In Stock
home
Turck-Shop
Sensors
Pressure Sensors
PT40R-2045-IOL-H1141
Technical Data
Downloads
Electrical output
2 x switching output
Ambient temperature max. (°C)
85
Ambient temperature min. (°C)
-30
Approvals
cULus
Communication protocol
IO-Link
Electrical connection
Connector
Connector type
M12 x 1
Design
Without display
Housing material
Stainless-steel/Plastic
Housing quality
1.4305 (AISI 303)/polyarylamide 50% GF UL 94 V-0
Material pressure transducer
Stainless steel 1.4016 (AISI 430)
Process connection
7/16″-20 UNF female thread (Schrader)
Media temperature max. (°C)
135
Media temperature min. (°C)
-40
Pressure range
0...40 bar
Operating voltage
DC
Pressure type
Relative pressure
Protection class
IP67
Switching element function
NO/NC
Key Features
Communication protocol
IO-Link
Electrical output
2 x switching output
Process connection
7/16″-20 UNF female thread (Schrader)
Price Group
G1
List Price
PLN 766.36
Item Total
PLN 766.36
