Ultrasonic sensor Receiver

M25URBQ8

Order ID no. 3079746

Ambient temperature max. (°C): 70
Ambient temperature min. (°C): -20
Connector type: M12 x 1
Construction size: ⌀ 25 mm
Design: Tube
Dimensions: 106 mm
Electrical connection: Connector
Function: Opposed mode sensor
Housing material: Metal
Housing quality: Stainless steel
Max. range (mm): 500
Operating mode: Receiver
Protection class: IP67, IP69
Radiation direction: straight
Special features: Chemical-resistant, Clear object detection, Resistant to chemicals
Switching element function: NO contact
